China Leading OEM Scaffolding Manufacturer

This is the inner tube of the scaffolding prop manufacturing. The inner tube is in OD48.3mm with holes on. Top plates are welded on one end of the scaffold tube. OD48.3mm scaffold tubes are inserted into the outer tube of the scaffolding props in construction. The lock pins of the scaffolding props are locked into the holes of the inner tube to fix scaffold props at a required height. https://www.wm-scaffold.com/adjustable-scaffolding-jack.html Wellmade Scaffold, China (ISO9001 & CE) sales@wm-scaffold.com

This is the heavy-duty steel scaffold ladders in manufacturing. The steel scaffold ladders are OD48.3mm scaffold tubes, with anti-slip rungs for steps. At the top, there are two scaffold spigots, the spigot is used to connect two scaffold ladders to a higher level in construction. OD48.3mm scaffold verticals are convenient to be secured by normal scaffold couplers. https://www.wm-scaffold.com/scaffold-ladder-netherlands.html Wellmade Scaffolod, China (ISO9001 & CE) sales@wm-scaffold.com

This is the ringlock ledger in manufacturing. OD48.3mm with cast steel ledger heads and wedge keys. Will be hot dip galvanized after welding. EN12810 standard to Europe https://www.wm-scaffold.com/ring-lock-scaffold.html Wellmade Scaffold, China (ISO9001 & CE) sales@wm-scaffold.com

This is the omega ladder access transom manufacturing. The omega ladder access transom is a component of British standard cuplock system modular scaffolding. It is in 1.3m centre to centre used to support three long boards and two short boards in cuplock construction that provides an opening area for ladder access. more details at https://www.wm-scaffold.com/cuplock-omega-ladder-access/ price contact sales@wm-scaffold.com

This is the high-load scaffolding system Crab 60 Scaffold. The Verticals are made of OD60mm scaffold tubes and high-grade steel of S355. The Crab 60 scaffolding system is designed to take a high load of weight in construction and shoring. The Crab 60 system includes parts and components of verticals, ledgers, braces, triangle frames, base jacks, u-head jacks, planks stairs etc. It can be hot dip galvanized or painted. https://www.wm-scaffold.com/crab-60-shoring-system.html Wellmade Scaffold, China (ISO9001 & CE) sales@wm-scaffold.com

This is the scaffold base plate manufacturing video. These scaffold base plates are with tubular spigots. The tubular spigot is inserted into the verticals of the scaffold system spreading loading from verticals to the ground. https://www.wm-scaffold.com/base-plate.html Wellmade Scaffold, China (ISO9001 & CE) sales@wm-scaffold.com

This is the truss ledgers of the steel ringlock system. It is a type of double-reinforced horizontal that can bear more weight than single/normal ledgers. The truss ledger sizes are 1.57m to 3.07m, made of OD48.3mm scaffold tube and two ledger heads at both ends connecting to rosettes on ringlock standards. https://www.wm-scaffold.com/ring-lock-scaffold.html Wellmade Scaffold, China (ISO9001 & CE) sales@wm-scaffold.com

Kwikstage Scaffolding System with "stars" on Standard. The stars are made of 4 pcs of V clips. Kwikstage scaffold ledgers include two types, one is thumbs+wedges, which is for Australia, the UK and Ireland, and another one is with C pressing+wedge pins at two ends. Hot dip galvanized and painted are the most popular surface finishes. More information: https://www.wm-scaffold.com/kwik-stage-scaffold.html Wellmade Scaffold, China (ISO9001 & CE) sales@wm-scaffold.com

Cuplock Scaffolding is a type of steel modular scaffolding with accessories of top and bottom cups, ledger blades etc. The cuplock system includes cuplock standards, ledger, braces, planks etc. Cuplock scaffolding will be hot dip galvanized or painted for anti-rusty purposes. Cuplock scaffold manufactured and conforms to the standards of EN 12810. More information on cuplock scaffolding: https://www.wm-scaffold.com/cup-lock-scaffold.html Wellmade Scaffold, China (ISO& CE) sales@wm-scaffold.com

This is the steel platform manufacturing video. It is the work platform parts for the ring system scaffold that conform to EN12810 standard. The scaffold planks are with O hooks that are used to connect with the ringlock scaffolding ledgers. The scaffold planks are 320mm in width and will be hot dip galvanized for anti-rusty purposes. https://www.wm-scaffold.com/ring-lock-scaffold.html Wellmade Scaffold, China (ISO9001 & CE) sales@wm-scaffold.com #scaffolding #scaffold #wellmade #constructionscaffolding #buildingscaffolding #ringlock #formwork

This is the video of the ringlock scaffold base collar. It is a starter of the ringlock system verticals. They have an inner tube of OD48.3mm and an Outer tube of OD57mm. The size of the base collar is 240mm. It is a type of European standard ringlock system starter. There are also longer types of base collars up to 430mm. More information and details: https://www.wm-scaffold.com/ring-lock-scaffold.html Wellmade Scaffold, China (ISO9001 & CE) sales@wm-scaffold.com #scaffolding #scaffold #ringlock #ringlock scaffold #ring lock scaffold #constructionscaffolding #wellmadescaffold #wellmade

This is the video of ringlock scaffolding ledgers manufacturing. The ledgers are tubular horizontal parts of the ring system made by OD48.3mm scaffold tubes. The ringlock scaffolding ledgers are manufactured according to EN12810 standards and sizes are from 0.73m to 3.07m. The ledger heads are cast steel type with pressed wedge pins. The ledger heads are welded at both ends of the OD48.3mm scaffold tubes. https://www.wm-scaffold.com/ring-lock-scaffold.html Wellmade Scaffold, China (ISO9001 & CE) sales@wm-scaffold.com #scaffolding #scaffold #formwork #ringlock #constructionscaffolding #buildingscaffolding #wellmadescaffold #wellmade

Ringock Scaffolding Standards 3m with 6 Rosettes and Spigot. It is a type of scaffold that conforms to EN12810 standard shipping to Europe. The standards are the vertical parts of the ring system and EN1090 and ISO3834 CE Certified More information about ringlock system parts: https://www.wm-scaffold.com/ring-lock-scaffold.html Wellmade Scaffold, China (ISO9001 & CE) sales@wm-scaffold.com #scaffolding #scaffold #ringlock #ribnglockscaffolding #wellmadescaffold #wellmade #chinascaffolding

3.07m Ringlock Scaffolding Ledgers are the longest horizontals for the European standard ring system. It is made of OD48.3mm high-strength steel scaffold tubes with cast steel ledger heads and pressed wedge pins. They will be hot dip galvanized after assembly and welded. The ringlock scaffolding ledgers are manufactured according to EN 12810 and CE (EN1090 and ISO 3834) standards. Galvanizing conforms to ISO 1461 More information about ringlock system scaffold: https://www.wm-scaffold.com/ring-lock-scaffold.html Wellmade Scaffold, China (ISO&CE Scaffold Factory) sales@wm-scaffold.com #scaffolding #scaffold #wellmade #ringlock #construction #building #wellmade #welllmadescaffold #chinamanufacturer

This is the one-board omega bracket for the cuplock system. It is used to support scaffold boards and battens closer to the building. The omega is with space for batten seats and a stop to avoid scaffold boards moving out. Sizes and spec: https://www.wm-scaffold.com/cuplock-hop-up-bracket/ Wellmade Scaffold, China (ISO9001 &CE) sales@wm-scaffold.com #scaffolding #scaffold #cuplock #construction #building #wellmade

Cuplock Scaffolding Standards 3.0m with 6 sets of top cups & bottom cups. It is the vertical parts of cuplock system and the top cups are drop forged type shipping to the USA Cuplock System Webpage: https://www.wm-scaffold.com/cup-lock-scaffold.html Wellmade Scaffold, China sales@wm-scaffold.com #scaffolding #scaffold #cuplock #cuplockscaffolding #cuplock #wellmadescaffold

This is the adjustable steel prop manufacturing video. The scaffolding props are OD48mm inner and OD60mm Outer, which can offer medium-duty shoring for concrete formwork and shuttering. There are also OD40/48mm, OD48/56mm light duty shoring prop jacks and heavy-duty formwork post shore with OD63/76mm inner and outer. More information about the adjustable steel props https://www.wm-scaffold.com/acrow-prop/ Wellmade Scaffold, China (ISO9001 & CE) sales@wm-scaffold.com #scaffolding #scaffold #props #scaffoldingprops #steelprops #scaffodlprops #formworkprops

This is the kwikstage scaffold standards manufacturing video Star Scaffold Vertical Poles Quick stage Modular Scaffold Parts https://www.wm-scaffold.com/kwikstage-scaffolding-standards.html Wellmade Scaffold, China (ISO9001 & CE) sales@wm-scaffold.com #scaffolding #saffold #kwikstage #quickstage #kwikstagescaffolding #kwikstagescaffold

This is the scaffold two-board bracket manufacturing video. It is a type of hop-up bracket used to support two widths of scaffold battens used in the building construction to make the scaffold platform closer to the building. More information about the two board brackets is on the webpage: https://www.wm-scaffold.com/kwikstage-2-board-hop-up-bracket.html Wellmade Scaffold, China (ISO9001 & CE) sales@wm-scaffold.com #scaffolding #scaffold #wellmade #kwikstage #tiebar #wellmadescaffold

Kwikstage Scaffold Tie Bars Scaffold Platform Protection for Hop Up Bracket of Kwikstage System https://www.wm-scaffold.com/kwikstage-tie-bar/ Wellmade Scaffold, China (ISO9001 & CE) sales@wm-scaffold.com #scaffolding #scaffold #kwikstage #quickstage #tiebar #scaffoldsystem #modularscaffold

This is the manufacturing video of the crowd control barriers. it is a type of galvanized barrier, that will be coated into red or white after welding. More information about the crowd control barrier: https://www.wm-scaffold.com/crowd-control-barriers/ Wellmade Scaffold, China (ISO9001 & CE) sales@wm-scaffold.com #scaffolding #scaffold #barriers #crowdcontrol #fence #scaffoldfence #scaffoldingfence

  Walk Through Frames Packed Well Waiting For Shipping to the USA Blue Coated Scaffold Frames Made Of OD42.7mm (1.68") Stucco and Plastering Scaffolding 3'x6'8" with Snap-On Lock Pins https://www.wm-scaffold.com/snap-on-walk-through-frame/ Wellmade Scaffold, China (ISO9001 & CE Certified) sales@wm-scaffold.com #scaffolding #scaffold #framescaffolding #americanstandard #scaffoldingframes #stucco #plastering #wellmadescaffold #wellmade #chinascaffolding walk through frame scaffolding American standard 3'x6'8"  - snap on lock pins for stucco and plastering project

  320mm Scaffold Planks 307cm Ringlock Scaffolding Platforms with Hooks for O Ledger Scaffold Steel Boards https://www.wm-scaffold.com/layher-allround-planks.html Wellmade Scaffold, China (ISO9001 & CE) sales@wm-scaffold.com #scaffolding #scaffold #ringlock #ringlockscaffold #ringlock #constructionscaffolding #buildingscaffolding #wellmadescaffold #wellmade 307cm Scaffold Planks for Ringlock O Ledger - 320mm scaffold platform galvanized - wellmade scaffold china

  3.07m Ringlock Scaffolding Ledgers Hot Dip Galvanized European Standard EN12810 Scaffolding Horizontals Steel Modular Scaffold Parts to Europe https://www.wm-scaffold.com/ring-lock-scaffold.html Wellmade Scaffold, China (ISO9001 & CE) sales@wm-scaffold.com #scaffolding #scaffold #ringlock #ringlockscaffolding #buildingscaffolding #constructionscaffolding #wellmadescaffold #wellmade Ringlock Scaffolding Ledgers 3.07m to Europe - EN12810 Standard Ring System Horizontals - Wellmade China

  Kwikstage Ledgers Galvanized In Scaffold Stillage Waiting For Shipping Horizontal Parts of Australian Standard Steel Quickstage Modular System https://www.wm-scaffold.com/kwik-stage-scaffold.html Wellmade Scaffold, China (ISO9001 & CE) sales@wm-scaffold.com #scaffolding #scaffold #kwikstage #quickstage #formwork #construction #shoring #shuttering #wellmadescaffold kwikstage ledgers in galvanized - horizontal parts of steel quickstage modular system-wellmade china
